The window film slitter rewinder is designed for slit rewinding window film, PE and PVC film, PET film, OPP film, aluminized film, laser film and any other composite film.

Features:
1. The tension uses vector frequency conversion and the PLC automatically calculates the roll diameter to realize the automatic tension control, more accurate
2. The pneumatic brake control unwinding makes the tension control softer, no residual torque, and high tension control precision

Main Data:

Name: Window Film Slitter Rewinder

Model:PPD-WFSR800

Unwinding roll width:1650mm

Unwinding roll diameter:max 800mm

Slitting rewinding roll diameter:max600mm

Slitting width:40mm-1650mm

Paper tube diameter for unwinding roll:3inch

Speed:max 400m/min

Voltage:220/380/415V option
