Window Film Slitter Rewinder
PPD-WFSR800
The window film slitter rewinder is designed for slit rewinding window film, PE and PVC film, PET film, OPP film, aluminized film, laser film and any other composite film.
Features:
1. The tension uses vector frequency conversion and the PLC automatically calculates the roll diameter to realize the automatic tension control, more accurate
2. The pneumatic brake control unwinding makes the tension control softer, no residual torque, and high tension control precision
Main Data:
Name: Window Film Slitter Rewinder
Model:PPD-WFSR800
Unwinding roll width:1650mm
Unwinding roll diameter:max 800mm
Slitting rewinding roll diameter:max600mm
Slitting width:40mm-1650mm
Paper tube diameter for unwinding roll:3inch
Speed:max 400m/min
Voltage:220/380/415V option
