Semi Automatic Stretch Film Slitting&Rewinding Machine

PPD-SASF500
Semi Automatic Stretch Film Slitting&Rewinding Machine
Get Quote

Semi automatic stretch film slitting&rewinding machine is a multi-functional model for slitting and rewinding for jumbo roll to small roll by same and different size width. By slitting and rewinding channels, the wrong layer can be corrected. the appearance of coil flatness is improved.

Main Features:
1.It is easy to operate and control for each operator
2.high speed model controlled by premium inverter
3. running stably with a thick wall frame of the machine body.we can make different width according to client's requirement.
4.Optionally, it can be added for coreless stretch film rewinding for additional.

Main Data:

Name:Semi Automatic Stretch Film Slitting&Rewinding Machine

Model:PPD-SASF500

Width of mother roll:500mm

Width of finish roll:50mm-max width

Mother roll diameter:max 500mm

Finish roll diameter:max180mm

Core of mother roll:3inch

Core of finish roll:1.5/2/3inch

Speed:max600m/minute

Power:2.37kw

Voltage:220/380/415V,50Hz

Different width 600mm,1000mm,1200mm can be customized.
