Semi Auto Embossed Aluminum Foil Rewinder

PPD-EAF450
Semi Auto Embossed Aluminum Foil Rewinder
Get Quote

The semi auto embossed aluminum foil rewinder is a 2 shaft exchanged model for embossed aluminum foil roll rewinding. The aluminum foil roll will be embossed after the special embossing roll which is wonderful.

It works with PLC program, touch screen for simple operation.



Features:

1. The unwinding roll uses air shaft to adjust the roll, 3 inch or 6 inch air shaft optional

2. Unwinding roll bearing weight ≤250kg

3. Automatic tension control

4. Metal embossing roller, embossing pattern is customized according to customer requirements

5 The aluminum foil is well combined, the pattern is clear, and the three-dimensional effect is strong.

Main Data:

Name:Semi Auto Embossed Aluminium Foil  Rewinder

Model:PPD-EAF450

Unwinding roll width:600mm

Unwinding roll ID:3/6inch option

Unwinding roll OD:600mm max,weight:max250kg

Finished roll width:same to unwinding roll

Finished roll ID:35/38/40mm option

Finished roll length:2-300m option

Design speed:max300rpm/min

Power:2.5kw

Voltage:220/380/415/440v option

NOTE:Different sizes can be customized.
