Rotary Numbering&Gluing Collating Machine

PPD-RNGC450
Rotary Numbering&Gluing Collating Machine
Get Quote

The machine uses frequency conversion stepless speed regulation, servo system paper feeding, PLC automatic control, photoelectric detection, automatic shutdown, start-up and jog, a machine with many functions;
No need to change gears and code holders for coding, you just need to set any number size on the display screen freely;
The numbering, barcode, page grabbing, page matching and slitting functions are complete, and the operation is simple;
One-time collation of 2-6 pages, pinhole paper guide, accurate paper feeding.

Main Data:

Name:Rotary Numbering&Gluing Collating Machine

Model:PPD-RNGC450

Maximum paper width 450mm:(17")

Number of collating layers:2-6 layers

Paper hole diameter :4±0.1mm

Working speed: 30~100m/min

Number of numbering machines: 1-42

Motor powe:r 0.75+1KW

Voltage:220V/50HZ

Machine weight: 700kg

NOTE:Different sizes can be  customized.
