Pneumatic Knife Nonwoven Fabrics Roll Slitting Rewinding Machine
PPD-PNSR1300
Pneumatic knife nonwoven fabrics roll slitting rewinding machine PPD-PNSR is a new series model for nonwoven fabrics slitting machine for the most advanced slitting knife installed, pneumatic knife.
This is the latest technology from Taiwan, through the pneumatic knife, the machine can cut for the flexible width of the finished roll, changing the width is very simple.
No bottom knife is required for this machine. The operator can save a lot of time by changing the bottom knife.
It is designed for single shaft rewinding for user friendly. The tension control is by automatic set.
With the high power of the magnetic power break clutch system, working together through the meter counting system, the rewinding roll length control is very accurate and precise in length setting.
Different widths are available for different options, 800,1300,1600,2500mm etc, the machine works perfectly on spunlace nonwoven, viscose nonwoven, PP nonwoven, pet non woven etc.
Main Data:
Name: Pneumatic Knife Nonwoven Fabrics Roll Slitting Rewinding Machine
Model :PPD-PNSR1300
Material: non woven fabrics
Unwind roll width:1300mm
Unwind roll ID:76mm
Unwind roll OD:1200mm max
Finished roll width: 30mm to max unwinnd roll width
Finish roll ID:76mm
Finish roll OD: max00mm option
Design speed:max200m/minute
Total power:2.5kw
Voltage:220/380/415/450v
Required pneumatic:0.3Mpa
NOTE:Different width 1600/1800/2500mm can be customized.
