Products

Plastic heat shrink film rewinder is used to rewind the jumbo roll from double-layer plastic film into two rolls of single-layer film.
Machine is suit for rewind of PE film,OPP film,PET film,BOPP film,PP film，PLA film nonwoven fabric etc.
Machine works with touch screen,PLC progarm and inverter control for simple operation.

Features:
1.Automatic meter counting,automatic stop once reach the setting length.
2. Unwinding tension: controlled by magnetic powder clutch.
3.Automatic tensioneer and autoatic track

Main Data：

Name:Plastic Heat Shrink Film Rewinder

Model:PPD-POFR500

Raw material:plastic heat shrink film,POF film,OPP film etc.

Jumbo roll width:500mm

Jumbo roll OD max600mm

Jumbo roll ID: 40-75mm,customized size

Rewind roll width:same as jumbo roll

Rewind roll ID:76mm

Rewind roll OD:max450mm

Speed:0-300m/min

Voltage:220/380/415V,50Hz

Power:4kw
