New Model Stretch Film Slitter Rewinder With Touch Screen

PPD-NSFRT500
New Model Stretch Film Slitter Rewinder With Touch Screen
Get Quote

New model stretch film slitter rewinder with touch screen is our latest model to slit and rewind PE stretch film, industrial stretch film, pallet stretch film, PE cling film and any other plastic film etc. The machine works with touch screen and PLC control for simple
operation ,2 exchange shafts to divide the large diameter film into several small diameter rolls, more efficient.


Features:
1. Different width can be set between 50 to 500mm, max to jumbo roll width.
2.Length setting adjustable,50/100/200meter option
3.Different size of sub-roll core diameter can be chosen,1.5/2/3inch can be chosen.

Technical Data:

Name:New Model Stretch Film Slitter Rewinder With Touch Screen

Model:PPD-NSFRT500

Jumbo roll width:500m

Jumbo roll weight:max50kg

Jumbo roll  inner core diameter:3inch(76mm)

Rewind roll width:50 to 500mm

Rewind roll  inner core diameter:1.5/2/3inch(38/50/76mm)

Rewind roll  outer core diameter:max180mm

Speed:max 650m/min

Power:1.7kw

Voltage:220/380/415V option

Air supply:0.2Mpa

NOTE:Any specifications can be customized.
