New Design 2 Turret Air Shaft PE Stretch Film Slitter

PPD-ASR500
New Design 2 Turret Air Shaft PE Stretch Film Slitter
Get Quote

New design 2 turret air shaft PE stretch film slitters is our latest design model for stretch film slitter rewinder.
This model uses an air shaft instead of a conventional mandrel in slitting rewinding operation, to ensure that the final product is flat and it is easier to unload the product roll.

Features:
1.It is a kind of multi-functional machine integrated with slitting and rewinding, divide the large diameter film into several small rolls.
2.With adjust slitting knife width, can get different width of product rolls.
3. It is convenient and flexible to adjust, low noise, frequency conversion speed regulation, and automatic rewinding counter.

Main Data:

Name:New Design 2 Turret Air Shaft PE Stretch Film Slitter

Model:PPD-ASSR500

Max width of parent roll:500 mm

Max diameter of parent roll:max400 mm

Inner diameter of parent roll:3inch

Production speed:600m/min

Width of sub-roll:50 mm-500 mm

Max diameter of sub-roll:max200 mm

Inner diameter of sub-roll:3inch air shaft or as customized sizes.

Paper core loading mode:By Manual

Cutting mode:By Knife

Voltage:220/440/415/380 V, 50/60 HZ, 3 phases.

Motor power:1.5 KW

NOTE:Different sizes can be customized.
