The liquid/sauce/paste automatic packaging machine can be mainly used for canning liquid or slurry less than 500 grams.

The machine uses stepper motor control, making the cursor tracking bag can be set and cut immediately, independent temperature PID control, the operation is simple and convenient.



Features:

1. Bag making, measuring, filling, sealing, cutting and counting are fully automatic.

2. Temperature independent PID control, suitable for different packaging materials.

3. The machine has a simple structure, small footprint and easy operation.

4. The transmission system is scientific and concise, and the maintenance is convenient.

Technical Data:

Name: liquid/sauce/paste automatic packaging machine

Model: PPD-LPM60

Metering method Rotary valve pump metering

Packaging material: PET/PE, PET/AL/PE, PET/CPP, PET/AL/CPP

Liquid volume: 1-20g/5-30g/ 20-100g optional

Packaging material size: max240mm, ID: 76mm

Bag size: 10-150mmx 10-120mm

Packing speed 35-60 packs/min

Voltage: 220V,50hz

Power: 1900W
