The kraft paper slitter rewinder is used for slitting and rewinding kraft paper jumbo roll into small kraft paper roll, the width of the finished product can be changed by adjusting the slitting blade.


Features:
1. The engine uses frequency conversion speed regulation to maintain stable operation during acceleration;
2. The slitting device uses a double-knife winding structure.

Technical Data:

Name: Kraft Paper Slitter Rewinder

Model:PPD-KPS1600

Jumbo roll width:1600mm

Slitting thickness: 60-300gsm

Jumbo roll OD:max1300mm

Rewind roll width: 30-1600mm

Diameter of rewinding air shaft: 3 inch

Production speed: 50-240m/min

Voltage:380V,50hz

Power:22kw
