Hi-speed Fully Auto Stretch Film Rewinding Machine
PPD-HARW500
Hi-speed fully auto stretch film rewinding machine is multi-functional for rewinding jumbo roll to baby roll for machine roll and hand roll.
The machine is designed at 1200m per minute for world top speed rewinding.
The machine is perfectly designed for PE stretch film, PE cling film, and PVC cling film rewinding.
One operator can operate 3 machines at the same time.
It is followed by PLC unit plus LCD touch screen for user friendly, it needs non-skilled operator to work on the machine.
Our machine uses world class brand top quality PLC device+LCD touch screen for user friendly, the operator just needs to enter the length setting, and wait for the ready roll to be packed in the carton box.
Main Specifications:
Name:Hi-Speed Fully Auto Stretch Film Rewinding Machine
Model:PPD-HARW500
Master reel width:max500mm
Master reel ID:3''
Master reel OD:500mm
Rewinding roll widthmax500mm
Stretch rewinding roll core ID:1.5/2/3inch
Speed:Max1200mtrs/ minutes
Total HP:4.37kw
Voltage:220/380/415/450V,50Hz option
