High speed automatic 4 shaft stretch film rewinding machine works with PLC programed, inverter control, touch screen for user friendly operation.
It is with fully automatic meter length counting, automatic processing, automatic heating wire cut off for end of rewind roll.
After rewinding from the jumbo roll, the rewinding roll widely used in household.
This model is rapidly change the shaft,4 shaft changing for non-stop production,it improves the production more than 50% than the market conventional model.
It is suitable for PE stretch film, pallet stretch wrap film,food stretch wrap film, PE/PVC food cling film etc with high speed production.

Main Data:

Name:High Speed Automatic 4 Shaft Stretch Film Rewinder

Model:PPD-4ASH500

Width of the unwind roll:500mm

Width of rewind roll:max500mm

Outer diameter of unwind roll:max400mm

Inner diameter of rewind roll:1.5/2/3inch

Outer diameter of rewind roll:max160mm

Speed:max900m/min

Voltage:220/380/415V,50Hz,3PH
