The machine is perfectly designed for rewinding cling film jumbo rolls into smaller rolls.
It can be easily controlled by an operator according to LCD monitoring+PLC device with auto conveyer system.
The machine model meets CE certificate of conformity for safety pass, Rohs certificate of ECO friendly pass. Using the automatic convery system, the finished product is delivered to the operator's side. Meatime, the operator does the packing work. Through smart HMI program unit with LCD touch screen plus digital panel dual way control, it provides heavy duty daily production for 24H. This lowers the lot for the labor cost divided by each finished product roll. It is suitable for PE food cling film, PVC cling wrap etc.

Technical Data:

Name：Fully Automatic PVC Cling Film Rewinding Machine

Model: PPD-ACR300

Material: PVC cling film

Mother roll width: 300mm

Mother roll ID: 3inch

Mother roll OD:450mm

Sub roll width:max300mm

Sub roll OD:max150mm

Sub roll ID:30/32/38/50/76mm

Speed: max900m/min

Voltage: 220/380/415v (option)

Power: 4kw
