Fully Automatic Pre Stretch Fluffy Roll Rewinder
PPD-APRW600-F
The fully automatic pre stretch fluffy roll rewinder is our latest design for rewinding pre stretch film fluffy rolls.
It is a multi-functional fully automatic rewinder, incorporating rewinding, pre stretching, edge folding, swing, fluffy etc.
Features:
1. The machine is suitable for pre stretch and general rewinding of industrial stretch films
2. With different gears, different stretching ratios can be obtained, and the film can be stretched at different different thickness and width;
3.PLC + HMI + Inverter control system, simple in operation and high efficiency.
Main Data:
Name:Fully Automatic Pre Stretch Fluffy Roll Rewinder
Model:PPD-APRW600-F
Width of mother roll:600mm
Width of finish roll:max600mm
Mother roll OD:max400mm
Finish Roll OD:max 180mm
Core of mother roll:3inch
Core of finish roll: 1.5/2/3inch
Pre stretching speed: max600/min
Standard roll rewind speed:max900m/min
Voltage:220/380/415V option
