The fully automatic baking paper silicon paper rewinding machine is a multi-function model to rewind silicon paper, baking paper, wax paper and any other food paper. It can also rewind aluminum foil.
It is PLC control, touch screen operation, auomatic raw mateiral feeding, automatic gluing, automatic rewinding, automatic exchange the paper core, automatic cutting, and automatic deliver the finished product by conveyor belt., Very easy to operate.

Main data:

Name:Fully Automatic Baking Paper Silicon Paper Rewinding Machine

Model:PPD-BPR450

Unwind roll width:450mm

Unwind roll OD:max400mm

Unwind roll paper core ID:76/152mm option

Rewind roll width:max450mm

Rewind roll paper core ID：35/38mm option

Rewind roll length:3-150m

Production speed:max2.5m/s

Magnetic powder braker:25Nm

Magnetic powder clutch:12Nm

Total power:4Kw

Voltage:220/380/415V option

NOTE:Different sizes can be customized.
