The fully auto stretch film folder edge rewinder incorporates automatic rewinding, automatic edge folding, automatic counting and automatic disconnecting functions together.
It is mainly used to divide the big roll into small rolls which can be easily operated by manual.

Features:
1.The machine can work as a standard rewinding machine.
2.Rewind the film and fold both sides.
3. Frequency conversion control motor control motor, speed adjustable, max650m/min.
4.The film can oscillate during rewinding.

Main Data:

Name:Fully Auto Stretch Film Folder Edge Rewinder

Model:PPD-AFER500

Width of mother roll:500mm

Width of finish roll:max500mm

Mother roll diameter:max400mm

Finish roll diameter:max180mm

Core size of mother roll:76mm

Core size of finish roll:76mm

Edge folding speed:max600m/min

Voltage:380V,50hz,3ph

Power:4.35kw
