Flat labeling machines are mainly used to automatically attach self-adhesive labels and self-adhesive films to flat and large arc product surfaces.
The machine sees the product through the sensor, sends the signal back to the labeling control system, controls the motor to the appropriate position to send the label and attaches it to the position where the product will be labeled, the product is flows through the labeling device, the label is combined, and the labeling is completed.
The machine has a simple structure, small space, easy to use and simple to maintain.

Features:
1. The labeling stability is good, the labeling is flat, no wrinkles, and no bubbles, which can meet the labeling of most products on flat and large arc surfaces;
2. The labeling position is adjustable and easy to use.
3. The whole machine is made of stainless steel and high-grade aluminum alloy, and the overall structure is stable and beautiful.

Main Data：

Name：Flat Labelling machine

Model：PPD-LM180

Suitable label width:10-140mm

Speed: 20～180pcs/min

Voltage: 220V,50/60Hz

Machine Dimension: 1500×750×1600mm (L×W×H)

Weight: 200Kgs
