Craft Paper Blank Paper Slitter Rewinder
PPD-CPBPS1000
Craft paper blank paper slitter rewinder is ideal of cutting of craft paper,blank paper,paper-plastic composite paper,bopp film,PET film BOPP, PET, CPP, CPE, PVC film etc.
It adopts variable frequency speed regulation to maintain smooth operation during acceleration, automatically counts meters, and is easy to operate.
Features:
1. The rewinding adopts an air shaft structure, which is convenient for loading and unloading.
2.Two shaft slitting rewinding,more efficient.
3. The machine is equipped with 10 round knives.
Main Technical Data:
Name:Craft Paper Blank Paper Slitter Rewinder
Model:PPD-CPBPS1000
Material thickness:20-300gsm
Jumbo roll width:max1000mm
Jumbo roll ID:76mm
Jumbo roll OD:max1200mm
Rewinding roll OD:max600
Rewinding roll ID:76mm
Slitting Rewinding Width:50-1000mm
Speed:10-200m/min
Power:6.5kw
Voltage:220V/380V/415V option
