Coreless Aluminum Foil Roll Rewinding Machine

PPD-CAFR600
Coreless Aluminum Foil Roll Rewinding Machine
Get Quote

The coreless aluminum foil roll rewinding machine is specialized in rewinding foilroll, paper roll, film roll small diameter roll and paper coreless. Such as wallpaper roll, aluminum foil roll, book cover roll, gift paper roll, advertisement paper roll, car windows film roll, solar film roll, tablecloth, poster, school sticker, decoration paper etc. The machine is controlled by PLC, indicated by touch
screen, servo motor length adjustment, mangnetic powder brake and clutch for tension control, simple in operation.

Main Data:

Name:Coreless Aluminium Foil Roll Rewinding Machine

Model:PPD-CAFR600

Jumbo roll widh:600mm

Jumbo roll OD:600mm

Jumbo roll ID:3inch

Rewinding roll width:max600mm

Rewinidng roll OD:max260mm

Production speed:200m/min

Rewinding roll ID: 25mm, 30mm, 35mm(or according to customers' requirement)

Voltage:220/380/415v,3ph

NOTE:Different sizes can be customized.
