Automatic Three Side Sealing Bag Making Machine(Two Servos)
PPD-600B
Automatic three-side sealing bag making machine(two servos)is a processing machinery suitable for packaging prefabricated bags made of various plastic composite films, aluminum foil composite films, paper-plastic composite films,BOPP, PET, CPP,ALU, and Nylon etc plastic laminated film and other materials.
Machine adopts PLC two servo traction control,temperature centralized
control, reducing electricity consume. The feeding system adopts magnetic brake tension control, and ensures the smoothness of the material .
Features:
1.Unwinder Structure:Vertical error rectifying in out feeding frame
2.Unwind tension control:Unwind magnetic brake controls
3.nitiative feeding unit:Independent AC inverter motor controls the unwinder
4.Control mode:floating dancing roller displacement sensor controls unwind speed
Main Data:
Name:Three Side Sealing Bag Making Machine(Two Servos)
Model:PPD-600B
Main Raw Material:BOPP, CPP, PET, NYLON, plastic laminated film, multiplayer extrusion blown film, pure aluminum, aluminum-plating laminated film, paper-plastic laminated film
Unwind roll size:φ800*1250mm
Bag Type:Three Side Seal
Bag size:60-580mm x 60-380mm
Bag making speed:180-200cut/min
Normal sealing width:5-60mm
Voltage:380V,50Hz
Power:35Kw
