Automatic pre-stretching film flufft rewinder is an efficient and intelligent industrial equipment, mainly used for rewinding and pre-stretching of PE winding film. Machine adopts Siemens series PLC, Siemens touch screen and Siemens inverter to realize the automation of parameter setting ,speed control and stable running.

Features:
1. The stretching ratio is controlled by the motor (such as 100%-300% adjustable), which reduces the material thickness and cost, and improves the uniformity and tightness of the coil.
2.Machine is equipped with an electric heating wire cutting device to support continuous production and reduce manual intervention.
3. This model uses NSK bearings to ensure more stable machine operation.

Name: Automatic Pre-stretching Film Fluffy Rewinder(Siemens System)

Model: PPD-APRE500

Width of parent roll: 500mm

Inner diameter of parent roll: 3 inches

Outer diameter of parent roll: maximum 500mm

Width of product roll: 500mm

Outer diameter of product roll: maximum 180mm

Inner diameter of product roll: 2/3 inch (optional)

Pre-stretching rewinding speed: max600rpm/min

Standard speed: max900m/min

Power: 4kw

Voltage: 220/380/415V, 50Hz
