Automatic paper tube cutter is an automatic paper tube, paper core cutter machine designed for heavy duty, less labor involved, it is widely used for various paper tube cutting.

Features：
1. PLC and touch screen control, you can directly input cutting parameters and monitor operating status on the screen.
2. The cutters are driven independently, and the cutting of each knife can be set independently.
3. The machine uses alloy steel blades for cutting, and the cuts are bright and smooth.

Technical Parameter：

Name:Automatic Paper Tube Cutter

Model:PPD-A3

Tube length:50-2000mm

Tube diameter:50-170mm

Blade quantity:12 pcs

Cutting speed:6-12m/min

Cutting method:Papa-tube rotate, blade-axes without rotating

Loading or reduction method:hand

Down blade way:pneumatic

Speed adjustment and control:transducer

Main-spindle rotation speed :300-1000r/min

Cutting thickness:2mm-18mm

Winding core rod:Within 80mm

Power input:3x380V

Mainframe power:3kw

Mainframe size:L*W*H 3100x900x1300 (mm)

Total weight:580kg
