Automatic 5 Turret Food Cling Film Perforation Labelling Rewinding Machinery
PPD-5SH300
Automatic 5 turret food cling film perforation labelling rewinding machinery is a new model of fully automatic PVC cling film, and PE cing film, food stretch film rewinding machine, it is an upgraded model from The Italy automatic machine, we developed it more than in Italy machine and more practical and economical selling price.
it has core auto loaading, 5 shafts auto exchanging for rewinding, the speed is double than other machine.Auto warning when there is no paper core.free setting for rewinding length.
The control of the LCD panel consists of ''PLC+ transducer+ signal switch''. The main electrical components of high quality are imported. Engine performance is very stable and reliable.
The LCD panel is ergonomically designed for easier operation and maintenance. It can be set as full auto, semi auto and manual.
As an option, the machine can provide a line of perforation during rewinding, it can easily cover a plate according to the desired distance of 250,300,350,450mm etc., this way it makes the use easier and less -waste during use.
The machine can produce a labeling attaching device, the label can provide the direction of the cling film roll to easily find the beginning of the film roll.
Technical Data:
Name:Automatic 5 Turret Food Cling Film Perforation Labelling Rewinding Machinery
Model:PPD-5SH300
Mother roll width:300mmmm
Mother roll inner core:3''
Mother roll outer diameter: Max 475mm
Finished roll core:35/38/40mm options
Finished roll length 5-150m
Finished roll width 300mm
Speed:Max 650m/min
Finish roll max outer diameter:130mm
Voltage:220/380415/450v,3 ph
Power:4.37kw
Note:Different specs are acceptable for on a customized machine.
