The machine is 2 shaft model for rewinding jumbo roll of silicon paper, baking paper, wax paper, PE coated paper, bakery paper to small house roll the setting length is every flexible from 2meter to 300meter etc. It is controlled by PLC unit, the speed
is by inverter. Through touch screen operation, the user only needs to enter the length setting, It has Chinese-English interchange for display.
The tension control is in the automatic device, the break system uses magnetic power of 50NM, to ensure that the jumbo roll is stable break control.
The machine is for automatic stop when the setting length is reached, automatic paper core shaft replacement and automatic food paper roll cutting.

Main data:

Name:2 Shaft Silicon Paper Baking Paper Rewinder

Model:PPD-2SHBR450

Unwind roll width:max450

Unwind roll core diameter:3inch

Unwind roll OD:600mm max

Finished product width:max 450mm

Finished product core diameter:35/38/40mm

Finished product length setting:2-300meter

Speed:300rpm/min max

Total power:2.2kw

Note:Any custmized model is accepted with provided specification.
